Frameset |
|
Frame |
OCLV Mountain Carbon main frame, alloy 1x-specific stays, ABP, Boost148, Knock Block, EVO link, E2 tapered head tube, Mino Link, Control Freak internal routing, Carbon Armor, ISCG 05, G2 Geometry, 150 mm travel |
|
Front suspension |
RockShox Yari RC, Solo Air, Motion Control damper, E2 tapered steerer, Boost110, G2 Geometry w/51 mm offset, 160 mm travel |
|
Rear suspension |
RockShox Deluxe RT3, RE:aktiv with Thru Shaft 3-position damper, tuned by Trek Suspension Lab, 230x57.5 mm |
|
Wheels |
|
Wheels |
Bontrager Line Comp 30, Tubeless Ready, 54T Rapid Drive, Boost110 front, Boost148 rear, tubeless strips included, valves sold separately |
|
Tires |
Bontrager SE4 Team Issue, Tubeless Ready, Core Strength side walls, aramid bead, 29x2.40˝ |
|
Drivetrain |
|
Shifters |
SRAM NX, 11-speed |
|
Rear derailleur |
SRAM NX, Roller Bearing Clutch |
|
Crank |
SRAM Descendant 6k Eagle, 32T Direct Mount X-Sync |
|
Bottom bracket |
PF92 |
|
Cassette |
SRAM PG-1130, 11-42, 11-speed |
|
Chain |
SRAM PC-1110 |
|
Pedals |
Not included |
|
Components |
|
Saddle |
Bontrager Evoke 2, chromoly rails |
|
Seatpost |
Bontrager Drop Line, internal routing, 31.6 mm (15.5: 100 mm/17.5 & 18.5: 125 mm/19.5 & 21.5: 150 mm) |
|
Handlebar |
Bontrager Line, 35 mm, 27.5 mm rise, 780 mm width |
|
Stem |
Bontrager Line, Knock Block, 35 mm, 0-degree, 50 mm length |
|
Grips |
Bontrager Rhythm, dual lock-on |
|
Headset |
Knock Block Integrated, sealed cartridge bearing, 1-1/8˝ top, 1.5˝ bottom |
|
Brakeset |
SRAM Guide R hydraulic disc |
