Frame |
Alpha Platinum Aluminium, ABP, Boost148, Knock Block steerer stop, Full Floater, EVO link, tapered head tube, Mino Link, Control Freak internal routing, downtube guard, PF92, ISCG 05, G2 Geometry, 130 mm travel |
|
Front suspension |
RockShox Reba RL, Solo Air, Motion Control RL damper, tapered steerer, Boost110, G2 Geometry w/51 mm offset, 130 mm travel |
|
Rear suspension |
Fox Performance Float EVOL, 3-position DPS damper, tuned by Trek Suspension Lab, 210x52.5 mm |
|
Wheels |
|
Wheels |
Bontrager Line Comp 30, Tubeless Ready, 54T Rapid Drive, Boost110 front, Boost148 rear, tubeless strips and valves sold separately |
|
Tires |
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, 120tpi, aramid bead, 29x2.40˝ |
|
Drivetrain |
|
Shifters |
SRAM NX Eagle, 12 speed |
|
Rear derailleur |
SRAM NX Eagle, Roller Bearing Clutch |
|
Crank |
SRAM NX Eagle DUB, 32T Direct Mount |
|
Bottom bracket |
SRAM DUB Press Fit, 92 mm |
|
Cassette |
SRAM XG-1230 Eagle, 11-50, 12-speed |
|
Chain |
SRAM NX Eagle |
|
Pedals |
Not included |
|
Components |
|
Saddle |
Bontrager Arvada |
|
Seatpost |
Dropper post, Bontrager lever, 31.6 mm, internal routing |
|
Handlebar |
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
|
Stem |
Bontrager Rhythm Comp, 31.8 mm clamp, 0-degree |
|
Grips |
Bontrager XR Trail Comp, nylon lock-on |
|
Headset |
Knock Block Integrated, sealed cartridge bearing, 1-1/8˝ top, 1.5˝ bottom |
|
Brakeset |
Shimano MT400 hydraulic disc |
