Frame |
Alpha Platinum Aluminium, ABP, Full Floater, EVO link, tapered head tube, Mino Link, MicroTruss, internal derailleur and dropper post routing, downtube guard, PF92, Boost148, G2 Geometry on 29ers, 100 mm travel |
Front suspension |
RockShox Recon RL, Solo Air, Motion Control damper, remote lockout, tapered steerer, Boost110, G2 Geometry w/51 mm offset on 29ers, 100 mm travel |
Rear suspension |
Fox Performance Float DPS, 2-position remote, tuned by Trek Suspension Lab, 6.5x1.5˝ |
Wheels |
Wheels |
Bontrager Kovee Comp 23, Tubeless Ready, Boost110 front, Boost148 rear, tubeless strips included, valves sold separately |
Tires |
Bontrager XR2 Team Issue, Tubeless Ready, 120 tpi, aramid bead, 29x2.20˝ (13.5 & 15.5: 27.5x2.20˝) |
Drivetrain |
Shifters |
SRAM NX Eagle, 12 speed |
Rear derailleur |
SRAM NX Eagle |
Crank |
SRAM NX Eagle DUB, 32T Direct Mount |
Bottom bracket |
SRAM DUB Press Fit, 92 mm |
Cassette |
SRAM XG-1230 Eagle, 11-50, 12-speed |
Chain |
SRAM NX Eagle |
Pedals |
Not included |
Components |
Saddle |
Bontrager Montrose Comp |
Seatpost |
Bontrager Rhythm Elite, 31.6 mm, 0 mm offset |
Handlebar |
Bontrager alloy, 31.8 mm, 5 mm rise, 720 mm width |
Stem |
Bontrager Elite, 31.8 mm, 7-degree |
Headset |
FSA IS-2, 1-1/8˝ top, 1.5˝ bottom |
Brakeset |
Shimano MT500 hydraulic disc |
