Frame |
Alpha Platinum Aluminium, ABP, Boost148, Knock Block steerer stop, EVO link, tapered head tube, Mino Link, Control Freak internal routing, downtube guard, ISCG 05, 150 mm travel |
|
Front suspension |
RockShox Yari RC, DebonAir, Motion Control RC damper, tapered steerer, Boost110, G2 Geometry w/51 mm offset, 160 mm travel |
|
Rear suspension |
RockShox Deluxe RT3, RE:aktiv with Thru Shaft 3-position damper, tuned by Trek Suspension Lab, 230x57.5 mm |
|
Wheels |
|
Wheels |
Bontrager Line Comp 30, Tubeless Ready, 54T Rapid Drive, Boost110 front, Boost148 rear, tubeless strips included, valves sold separately |
|
Tires |
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, 120tpi, aramid bead, 29x2.40˝ |
|
Drivetrain |
|
Shifters |
SRAM GX Eagle, 12 speed |
|
Rear derailleur |
SRAM GX Eagle, Roller Bearing Clutch |
|
Crank |
Truvativ Descendant 6k Eagle DUB, 32T Direct Mount |
|
Bottom bracket |
SRAM DUB Press Fit, 92 mm |
|
Cassette |
SRAM XG-1275 Eagle, 10-50, 12-speed |
|
Chain |
SRAM GX Eagle |
|
Pedals |
Not included |
|
Components |
|
Saddle |
Bontrager Arvada, hollow chromoly rails |
|
Seatpost |
Bontrager Line, internal routing, 31.6 mm, 15.5: 100 mm, 17.5 & 18.5: 125 mm, 19.5 & 21.5: 150 mm |
|
Handlebar |
Bontrager Line, 35 mm, 27.5 mm rise, 780 width |
|
Stem |
Bontrager Line, Knock Block, 35 mm clamp, 0-degree |
|
Grips |
Bontrager XR Trail Elite, alloy lock-on |
|
Headset |
Knock Block Integrated, sealed cartridge bearing, 1-1/8˝ top, 1.5˝ bottom |
|
Brakeset |
SRAM Guide R hydraulic disc |
